An fitting to inches. Stainless tubing an equivalent all dimensions are in inches unless otherwise noted. 316 38 24 sae 4 an. Read fitting size where it intersects the vertical line. 1 metre is equal to 32808398950131 feet or 39370078740157 inch. You can convert any an fitting to its nominal inch size by dividing the an number by 16 as follows. That is the size of the line.
The pit stop usa difference were the experts we help you find a way to win. An which stands for armynavy sizes represent 116th of an inch. Since tubing and hoses have assorted wall thicknesses depending on manufacturers the designated size number does not necessarily tell us anything about the inside diameter id of the plumbing component. Thread size chart for an fittings. Pipe thread size chart use the diagram below to find pipe thread size. Each an size also uses its own standard thread size.
4 an 416 or 14. Lay your fitting over the appropriate drawing to determine what size fitting you have. The answer is 0083333333333333. 3an hose has the same id as a 316 tube. This means that 6an hose will not introduce any appreciable flow restriction in a fuel system designed around 38 od rigid tubing. An line sizes will have a dash preceding the line size.
That chart tells you the wrench size to use on the fitting. The following chart shows the each sizes thread per inch count the id. While an fittings depend on the outside diameter of a tube for sizing npt fittings depend on the interior diameter id of the fitting itself. 14 716 20 sae. An lines orb ports and the appropriate port adapter fittings are measured in inchfractional sizes. For example 8an hose has the same id as a 12 nominal tube 816 12.
For example take a 08 an line. Huge selection over 100000 products from the top performance brands. The si base unit for length is the metre. Use this handy chart to determine the an fitting size based on corresponding thread sizes. For example an 8 an fitting translates to an 816 inches or 12 inch. Not what size the line is.
Of the fitting and the an fitting size with the closest matching idinside dimension. The an numbers refer to the tubing od in sixteenths of an inch. The number after the dash refers to the number of sixteenths of an inch the line size is. However this system does not specify the id inside diameter of the tubing because the tube wall can vary in thickness. Tube size od thread size wrench size 2. An fittings are a flare fitting using 37 flared tubing to form a metal metal.
Just to clear things up here. An fittings hose and tubing size reference charts. We assume you are converting between foot and inch. Therefore a 8 an size would be equal to 1 2 inch od tube. So a 8 line is a 12 inch line and uses a 78 wrench on the fitting. Place fitting against base line.
